DXTECH-EL 3000W Metal Aluminum Fiber Laser Cutting Machine with Exchange Platform for Sale in Venezuela
Price:
$20,000.00 /Set
Price Range :
$20,000.00 – $60,000.00
EL-Series is a 2000W metal stainless steel exchange platform fiber laser cutting machine for sale in Armenia. This is a high-precision, high-speed entry-level sheet metal cutting machine. Its power supports 1-6KW, and it can cut most metal plates within 25mm, such as 4mm stainless steel, 8mm low carbon steel, 5mm aluminum plate, etc. This machine adopts an open, stand-alone design with a simple structure and a switching platform, which greatly improves work efficiency. The installation and maintenance of this machine are also very convenient, and the operating cost is low. It is suitable for various industries such as sheet metal processing, cabinet production, and agricultural machinery production.
DXTECH-EL 3000W Metal Aluminum Fiber Laser Cutting Machine with Exchange Platform for Sale in Venezuela
Laser CNC Machines Video
DXTECH-EL 3000W Metal Aluminum Fiber Laser Cutting Machine with Exchange Platform for Sale in Venezuela
Exchange Platform Fiber Laser Cutting Machine for Steel, Iron advantages
1. With double platform, saving more than 50% of space and bring double production benefits.
2.Independent control cabinet
1) Dust proof: all electrical components and laser sources are built in an independent control cabinet to prevent dust pollution.
2) Automatic thermostat: equipped with an automatic constant temperature air conditioner, which can prevent the damage to the components due to the high temperature.
3.Thick-walled carbon steel pipe welding bed
Adopting high-quality carbon steel welding bed, it is more stable and durable. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
4. World brand guides, racks and other components, make you no longer worry about the precision of cutting.
DXTECH-EL 3000W Metal Aluminum Fiber Laser Cutting Machine with Exchange Platform for Sale in Venezuela
Customer praise
What Customers Who Bought DXTECH AUS-1530EL Said:
Israel Customer
I bought a 3000W 8mm Metal Carbon Steel Exchange Platform Fiber Laser Cutting Machine for thin metal sheet from China DXTECH AUS 1 year ago. This machine is very cost-effective, easy to maintain and operate, and has obtained CE certification. Mr Zhang and his team are always helpful whenever we need any technical assistance, I highly recommend DXTECH AUSTRALIA!
Automatic exchange of platform
Adopts the dual-platform automatic exchange system with the platform exchange time of 20-25s, which greatly improves work efficiency.
Thick-walled carbon steel pipe welding bed
Adopting high-quality carbon steel welding bed, it is more stable and durable. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
Aviation aluminum beam
1) It has the characteristics of corrosion resistance, light weight, and high rigidity, which ensures high-speed movement during laser processing.
2) It has perfect dynamic performance, such as anti-distortion, anti-overturning, anti-deformation, etc., ensuring higher cutting accuracy.
Ospri Laser cutting head
Multi-level perforation
It has multi-level perforation process and ultra-fine cutting functions. Compared with Au3tech laser head, its cutting precision is higher, and the processing effect will be better.
Autofocus
Without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
Technical Parameters
| Model | DXTECH-1530EL | DXTECH-1540EL | DXTECH-2040EL |
| Working area (mm) | 1515*3030 | 1515*4040 | 2020*4040 |
| Worktable bearing capacity | 800kg | 950kg | 1300kg |
| Positioning accuracy | ±0.03mm | ±0.03mm | ±0.03mm |
| Repositioning accuracy | ±0.02mm | ±0.02mm | ±0.02mm |
| Max. exchange time | 18s | 21s | 22s |
| Max. acceleration | 1.5G | 1.5G | 1.5G |
| Laser power | 1kW – 6kW | 1kW – 6kW | 1kW – 6kW |
| Laser | Multiple options | Multiple options | Multiple options |
| Machine bed | tube welding bed/sheet welding bed | tube welding bed/sheet welding bed | tube welding bed/sheet welding bed |
| Max. running speed | 140m/min | 140m/min | 140m/min |
DXTECH-EL 3000W Metal Aluminum Fiber Laser Cutting Machine with Exchange Platform for Sale in Venezuela
Application
Metal sheet laser cutting machines can cut a wide range of metals, even though highly reflective metals. For instance, carbon steel, stainless steel, aluminum, copper, brass, titanium, nickel, and various alloys. The sheet metal laser cutting machine has extensive applications in decoration, infrastructure, construction, microelectronic, advertising, kitchen appliance, automobile and other equipment manufacturing, and other industries.
